Question 1: (80 marks)

An electronic component is mounted on a base 60 x 60 mm. The base temperature is 80oC. It is to be cooled with ambient air at 30oC. The heat transfer coefficient can be taken as 15 W/m2 K. Neglect radiative heat transfer.

1. Calculate the maximum heat dissipation possible if no fins are used. (5 marks)
2. 2. Calculate the heat dissipation possible if a single aluminum (k = 240 w/m K) fin 30 mm high is used over the entire area. Note that it is equivalent to keeping a 60 x 60 x 30 mm aluminum block on the hot base. First make correction for length of the fin as it will not be insulated tip. (15 marks)
3. Find what error will be introduced if it is assumed that fin tip is insulated. (10 marks)
4. Now replace the aluminum block with n number of 3 x 3 mm square fins equally spaced. Make an analysis with n = 121, 36 and find the heat dissipation possible for each case and for uninsulated and insulated fin tip conditions.

(5 marks)

1. What is the % under prediction if insulated fin tip condition is used in each case. (5 marks)
2. Calculate the volume fraction of fins to total geometric volume in d). (5 marks)
3. If the same volume fraction is used as in the case of 121 fins, but the fin dimensions are changed to 5 x 5 mm, first calculate the number of fins (rounded up) and then calculate the total heat transfer. (15 marks)

Question 2: (5 marks)

Based on the information in Question 1, answer the following:

As the volume fraction of fins increases from 0 to 1, does the heat dissipation increase monotonically?

Question 3: (5 marks)

Based on the information in Question 1, answer the following:

For the same volume fraction of fins, should one use large number of small cross-sectional area fins or small number of larger cross-sectional area ones?

Question 4: (10 marks)

Create a 10-minute demonstration

Select any one of the questions above. Create and submit a Loom video/MS ppt video with webcam ON (showing your face) and screen capture showing how you solved the problem and plotted the results using IHT software or MS Excel or any other heat transfer software. The video length should NOT be more than 10 minutes. So, practice well before recording.
